D32 Pot Magnet - 40Kg Pull

Usage au sec — ne convient pas à une exposition prolongée à l'eau salée

The DM-PM-32 Pot Magnet is a compact and powerful clamping magnet designed to deliver strong holding force in a small form factor. Combining the performance of Neodymium (NdFeB N42) with the practicality of an M5 eye nut, it provides a convenient attachment point for securing tools, equipment, or components to steel surfaces. With a 32 mm diameter magnetic face, the magnet can support up to 40 kg vertically when in flush contact with a mild steel surface of equal thickness. The neodymium magnet is encased in a steel pot, concentrating the magnetic field and significantly increasing the adhesive force relative to its size. Specifications: Product Code: DM-PM-32 | Magnet type: Neodymium (NdFeB N42) | Coating: Nickel | Diameter: 32 mm | Thickness: 8 mm | Fixing: M5 eye nut with 5 mm counterbored hole | Maximum holding force: up to 40 kg (vertical pull) | Max operating temperature: 80°C.

Force de maintien : 40 kg · Face magnétique Ø : 32 mm · Grade : N42 · Revêtement : Nickel · Pays d'origine : Afrique du Sud
