D42 Pot Magnet - 77kg Pull

Uso en seco: no apto para exposición prolongada al agua salada

The DM-PM-42 Pot Magnet is a compact high-strength clamping magnet designed to deliver impressive holding power relative to its size. Combining the performance of Neodymium (NdFeB N42) with the practicality of an M6 eye nut, it provides a reliable attachment point for securing tools, equipment, or components to steel surfaces. With a 42 mm diameter magnetic face, the magnet can support up to 77 kg vertically when in flush contact with a mild steel surface of equal thickness. The neodymium magnet is embedded within a steel pot, concentrating the magnetic field to significantly increase the holding force. Specifications: Product Code: DM-PM-42 | Magnet type: Neodymium (NdFeB N42) | Coating: Nickel | Diameter: 42 mm | Thickness: 9 mm | Fixing: M6 eye nut with 6 mm counterbored hole | Maximum holding force: up to 77 kg (vertical pull) | Max operating temperature: 80°C.

Fuerza de sujeción: 77 kg · Cara magnética Ø: 42 mm · Grado: N42 · Recubrimiento: Nickel · País de origen: Sudáfrica
