D60 Pot Magnet - 130kg Pull

Uso en seco: no apto para exposición prolongada al agua salada

The DM-PM-60 Pot Magnet is a high-strength clamping magnet designed to deliver exceptional holding power in a compact form. Combining the performance of Neodymium (NdFeB N42) with the practicality of an M8 stainless steel eye nut, this magnet provides a reliable attachment point for securing or positioning equipment on steel surfaces. With a 60 mm diameter magnetic face, the magnet can support up to 130 kg vertically when in flush contact with a mild steel surface of equal thickness. The powerful neodymium core is encased in a steel pot, concentrating the magnetic field and significantly increasing the holding force for its size. Specifications: Product Code: DM-PM-60 | Magnet type: Neodymium (NdFeB N42) | Coating: Nickel | Diameter: 60 mm | Thickness: 15 mm | Fixing: M8 eye nut with 8 mm counterbored hole | Maximum holding force: up to 130 kg (vertical pull) | Max operating temperature: 80°C.

Fuerza de sujeción: 130 kg · Cara magnética Ø: 60 mm · Grado: N42 · Recubrimiento: Nickel · País de origen: Sudáfrica
