D36 Pot Magnet - 45Kg Pull

Tørr bruk – ikke for langvarig eksponering for saltvann

The DM-PM-36 Pot Magnet is a compact and powerful clamping magnet designed to deliver strong holding force relative to its size. Combining the performance of Neodymium (NdFeB N42) with the practicality of an M5 eye nut, it provides a convenient attachment point for securing tools, equipment, or components to steel surfaces. With a 36 mm diameter magnetic face, the magnet can support up to 45 kg vertically when in flush contact with a mild steel surface of equal thickness. The neodymium magnet is encased in a steel pot, concentrating the magnetic field and significantly increasing the adhesive force. Specifications: Product Code: DM-PM-36 | Magnet type: Neodymium (NdFeB N42) | Coating: Nickel | Diameter: 36 mm | Thickness: 8 mm | Fixing: M5 eye nut with 5 mm counterbored hole | Maximum holding force: up to 45 kg (vertical pull) | Max operating temperature: 80°C.

Holdekraft: 45 kg · Magnetflate Ø: 36 mm · Magnetkvalitet: N42 · Belegg: Nickel · Opprinnelsesland: Sør-Afrika
