D48 Pot Magnet - 92 Kg Pull

Tørr bruk – ikke for langvarig eksponering for saltvann

The DM-PM-48 Pot Magnet is a compact yet powerful clamping magnet designed to deliver exceptional holding strength for its size. Combining the performance of Neodymium (NdFeB N42) with the practicality of an M8 eye nut, it provides a secure attachment point for securing or positioning equipment on steel surfaces. With a 48 mm diameter magnetic face, the magnet can support up to 92 kg vertically when in flush contact with a mild steel surface of equal thickness. The neodymium magnet is encased within a steel pot, concentrating the magnetic field to significantly increase the holding force relative to its size. Specifications: Product Code: DM-PM-48 | Magnet type: Neodymium (NdFeB N42) | Coating: Nickel | Diameter: 48 mm | Thickness: 11.5 mm | Fixing: M8 eye nut with 8 mm counterbored hole | Maximum holding force: up to 92 kg (vertical pull) | Max operating temperature: 80°C.

Holdekraft: 92 kg · Magnetflate Ø: 48 mm · Magnetkvalitet: N42 · Belegg: Nickel · Opprinnelsesland: Sør-Afrika
